Cost-effective yet high-quality CNC machining for all your machine parts and components
We provide 4-axis turning with a machining capacity that can accommodate dimensions up to 1500mm longitudinal, 585mm vertical and 595mm traverse, complete with a 4th-axis chuck diameter of 205mm. We also have the capability to provide spiral milling.
Furthermore, we can undertake turning applications with a maximum capacity of 1100mm diameter at chuck and 750mm swing over saddle x 2 metres cts.
Our CNC machining capabilities
CNC turning
-
Maximum of 1100mm diameter with a maximum of 750mm clearance over the saddle x 2000mm between cts. Maximum diameter in the spindle bore 165mm.
-
Maximum of 560mm diameter with a maximum of 350mm clearance over the saddle x 1750mm between cts. Maximum diameter in the spindle bore 104mm.
-
Maximum of 480mm diameter with a maximum of 260mm clearance over the saddle x 3000mm between cts. Maximum diameter in the spindle bore 80mm.
​
CNC milling
-
Maximum longitudinal travel of 1525mm, 600mm cross travel and 540mm head travel. 4 axis milling applications.
We also provide a manual machining service
-
Manual turning applications with a maximum capacity of 1100mm diameter x 3 metres cts.
-
Vertical boring applications with a maximum capacity of 1000mm
-
Manual milling applications with a maximum capacity of 2.5 m nc
-
Horizontal boring and drilling applications with a maximum capacity of 1200mm x 1200mm.
-
Lifting capacity: 6.3 tonnes
Services and applications available:
-
Liquid nitrogen for shrink fitting of shafts, bushes etc
-
Fabrication and welding applications
-
Collection and delivery services
-
One-off custom designs and machining
-
Batch work
-
Project work undertaken
-
Design and build facility
-
Full traceability with internal inspection certificates upon request
